Newly Arrival Stainless Steel Tube For Boiler Tubes - Stainless Steel Sheet and Coil – Type 410 Product – Sihe
Newly Arrival Stainless Steel Tube For Boiler Tubes - Stainless Steel Sheet and Coil – Type 410 Product – Sihe Detail:
Stainless Steel Sheet and Coil – Type 410 Product
Stainless steel sheet & plate is often referred to as corrosion-resistant steel since it does not stain, corrode or rust as easily as regular carbon steel. Stainless steel sheet & plate is the perfect is the perfect solution for applications that require the metal to have anti-oxidation qualities.
Stainless steel products：
stainless steel coil tube
stainless steel tube coil
stainless steel coil tubing
stainless steel coil pipe
stainless steel coil tube suppliers
stainless steel coil tube manufacturers
stainless steel pipe coil
Product Line Description
Cold Rolled, Annealed No. 2B Finish
·Can also be furnished:
No. 3 Finish – Polished One or Two Sides
No. 4 Finish – Polished One or Two Sides
Non-Magnetic (May be Slightly magnetic when cold worked)
·Paper Interleaved or Vinyl Masked:
22 Gauge and Heavier
A.S.T.M. A240/A480 ASME SA-240
A.S.T.M. A262 Prac E
410 Stainless Steel Chemical Composition
|
Grade |
C |
Mn |
Si |
P |
S |
Cr |
MO |
Ni |
N |
|
|
410 |
min. |
– |
– |
– |
– |
– |
11.5 |
– |
– |
– |
|
max. |
0.15 |
1.0 |
1.0 |
0.040 |
0.030 |
13.5 |
0.75 |
– |
||
Stainless Steel 410 Mechanical Properties
|
Grade |
Tensile Strength (MPa) min |
Yield Strength 0.2% Proof (MPa) min |
Elongation (% in 50mm) min |
Hardness |
|
|
Rockwell B (HR B) max |
Brinell (HB) max |
||||
|
410 |
480 |
275 |
16 |
92 |
201 |
Stainless Steel 410 Physical Properties
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 410 | 7750 | 200 | 9.9 | 11.4 | 11.6 | 24.9 | 28.7 | 460 | 570 |
Equivalent Grades for 410 Stainless Steel
|
STANDARD |
WERKSTOFF NR. |
UNS |
JIS |
BS |
GOST |
AFNOR |
EN |
|
SS 410 |
1.4006 |
S41000 |
SUS 410 |
– |
– |
– |
– |
410 Stainless Steel Properties
Applications:
- Rapid transit cars, buses, aircraft, cargo containers
- Retractor springs
- Hose clamps
- Conveyors
- Bottling machinery
- Jewelry
- Cryogenic vessels and components
- Still tubes
- Expand metal parts
- Mixing bowls
- Dryers
- Furnace parts
- Heat exchangers
- Paper mill equipment
- Oil refining equipment
- Textile industry
- Dyeing equipment
- Jet engine parts
- Welded storage tanks for organic chemicals
- Combustion chambers
- Furnace arch supports
- Kiln linings
- Smoke control ductwork
- Coal chutes
- Gauge parts
- Cutlery
- Fish hooks
- Glass molds
- Bank vaults
- Fasteners
- Skewers
- Dairy industry
- Burner and emission control components
- Recuperators
- Pipes, tubes
Features
1 commodity stainless steel sheet/Plate
2 material 201, 202, 304, 304L, 316, 316L, 309S, 310S, 317L, 321, 409, 409L, 410, 420, 430, etc
3 surface 2B, BA, HL, 4K, 6K, 8KNO. 1, NO. 2, NO. 3, NO. 4, NO. 5, and so on
4 standard AISI, ASTM, DIN, EN, GB, JIS, etc
5 specification
(1) thickness: 0.3mm- 100mm
(2) width: 1000mm, 1250mm, 1500mm, 1800mm, 2000mm, etc
(3) length: 2000mm2440mm, 3000mm, 6000mm, etc
(4) The specifications can be provided as clients’ requirement.
6 application
(1) Construction, decoration
(2) petroleum, chemical industry
(3) electrical appliances, automotive, aerospace
(4) house ware, kitchen appliances, cutlery, foodstuff
(5) surgical instrument
7 advantage
(1) High surface quality, clean, smooth finish
(2) Good corrosion resistance, durability than ordinary steel
(3) High strength and to deform
(4) Not easy to be oxidized
(5) Good welding performance
(6) The use of diversity
8 package
(1) Products are packed and labeled according to regulation
(2) According to customers’ requirement
9 delivery within 20 working days since we get the deposit,mainly according to your quantity and the ways of transportation.
10 payment T/T, L/C
11 shipment FOB/CIF/CFR
12 productivity 500tons/month
13 Note We can supply other grade products as customers’ requirement.
Standard & Material
1 ASTM A240 Standard
201, 304 304L 304H 309S 309H 310S 310H 316 316H 316L 316Ti 317 317L 321 321H 347 347H 409 410 410S 430 904L
2 ASTM A480 Standard
302, s30215, s30452, s30615, 308, 309, 309Cb, 310, 310Cb, S32615,S33228, S38100, 304H, 309H, 310H, 316H, 309HCb, 310HCb, 321H,347H, 348H, S31060, N08811, N08020, N08367, N08810, N08904,N08926, S31277, S20161, S30600, S30601, S31254, S31266,S32050, S32654, S32053, S31727, S33228, S34565, S35315,S31200, S31803, S32001, S32550, S31260, S32003, S32101,S32205, S32304, S32506, S32520, S32750, S32760, S32900, S32906, S32950, S32974
3 JIS 4304-2005 Standard SUS301L,SUS301J1,SUS302,SUS304, SUS304L, SUS316/316L, SUS309S, SUS310S, 3SUS21L, SUS347, SUS410L, SUS430, SUS630
4 JIS G4305 Standard
SUS301, SUS301L, SUS301J1, SUS302B, SUS304, SUS304Cu,SUS304L, SUS304N1, SUS304N2, SUS304LN, SUS304J1, SUSJ2,SUS305, SUS309S, SUS310S, SUS312L, SUS315J1, SUS315J2,SUS316, SUS316L, SUS316N, SUS316LN, SUS316Ti, SUS316J1,SUS316J1L,SUS317, SUS317L, SUS317LN, SUS317J1, SUS317J2,SUS836L, SUS890L, SUS321, SUS347, SUSXM7, SUSXM15J1, SUS329J1, SUS329J3L, SUS329J4L, SUS405, SUS410L, SUS429, SUS430, SUS430LX, SUS430J1L, SUS434, SUS436L, SUS436J1L,SUS444, SUS445J1, SUS445J2, SUS447J1, SUSXM27, SUS403,SUS410, SUS410S, SUS420J1, SUS420J2, SUS440A
Surface treatment
|
Itme |
Surface finishing |
Surface finishing methods |
Main application |
| NO.1 | HR | Heat treatment after hot rolling, pickling, or with treatment | For without the purpose of the surface gloss |
| NO.2D | Without the SPM | Method of heat treatment after cold rolling, pickling surface roller with wool or eventually a light rolling a matte surface processing | General materials,building materials. |
| NO.2B | After SPM | Giving No.2 processing materials appropriate method of cold light sheen | General materials, building materials ( most of the goods are processed ) |
| BA | Bright annealed | Bright heat treatment after cold rolling , in order to be more shiny, cold light effect | Automotive parts, home appliances, vehicles, medical equipment, food equipment |
| NO.3 | Shiny, coarse grain processing | The NO.2D or NO.2B processing timber No. 100-120 polishing abrasive grinding belt | Building materials, kitchen supplies |
| NO.4 | After CPL | The NO.2D or NO.2B processing timber No. 150-180 polishing abrasive grinding belt | Building materials, kitchen supplies, vehicles, medical equipment, food equipment |
| 240# | Grinding of fine lines | The NO.2D or NO.2B processing timber 240 polishing abrasive grinding belt | Kitchen appliances |
| 320# | More than 240 lines of grinding | The NO.2D or NO.2B processing timber 320 polishing abrasive grinding belt | Kitchen appliances |
| 400# | Close to BA luster | The MO.2B timber 400 polishing wheel polishing method | Building materials, kitchen utensils |
| HL(hair lines) | Polishing line having a long continuous processing | In a suitable size ( usually mostly No. 150-240 grit ) abrasive tape for as long as the hair, having a continuous processing method of polishing line | The most common building materials processing |
| NO.6 | NO.4 processing less than the reflection , the extinction | NO.4 processing material used for polishing Tampico brushing | Building materials, decorative |
| NO.7 | Highly accurate reflectance mirror processing | No. 600 of the rotary buff with a polishing | Building materials, decorative |
| NO.8 | Highest reflectivity mirror finish | Fine particles of abrasive material in order polishing , mirror polishing with a polishing | Building materials, decorative, mirrors |
INTERNATIONAL
| U.S.A. | GERMANY | GERMANY | FRANCE | JAPAN | ITALY | SWEDEN | U.K. | E.U. | SPAIN | RUSSIA |
| AISI | DIN 17006 | W.N. 17007 | AFNOR | JIS | UNI | SIS | BSI | EURONORM | UNE | GOST |
| 201 | SUS 201 | |||||||||
| 301 | X 12 CrNi 17 7 | 1.431 | Z 12 CN 17-07 | SUS 301 | X 12 CrNi 1707 | 23 31 | 301S21 | X 12 CrNi 17 7 | X 12 CrNi 17-07 | |
| 302 | X 5 CrNi 18 7 | 1.4319 | Z 10 CN 18-09 | SUS 302 | X 10 CrNi 1809 | 23 31 | 302S25 | X 10 CrNi 18 9 | X 10 CrNi 18-09 | 12KH18N9 |
| 303 | X 10 CrNiS 18 9 | 1.4305 | Z 10 CNF 18-09 | SUS 303 | X 10 CrNiS 1809 | 23 46 | 303S21 | X 10 CrNiS 18 9 | X 10 CrNiS 18-09 | |
| 303 Se | Z 10 CNF 18-09 | SUS 303 Se | X 10 CrNiS 1809 | 303S41 | X 10 CrNiS 18-09 | 12KH18N10E | ||||
| 304 | X 5 CrNi 18 10 | 1.4301 | Z 6 CN 18-09 | SUS 304 | X 5 CrNi 1810 | 23 32 | 304S15 | X 6 CrNi 18 10 | X 6 CrNi 19-10 | 08KH18N10 |
| X 5 CrNi 18 12 | 1.4303 | 304S16 | 06KH18N11 | |||||||
| 304 N | SUS 304N1 | X 5 CrNiN 1810 | ||||||||
| 304 H | SUS F 304H | X 8 CrNi 1910 | X 6 CrNi 19-10 | |||||||
| 304 L | X 2 CrNi 18 11 | 1.4306 | Z 2 CN 18-10 | SUS 304L | X 2 CrNi 1911 | 23 52 | 304S11 | X 3 CrNi 18 10 | X 2 CrNi 19-10 | 03KH18N11 |
| X 2 CrNiN 18 10 | 1.4311 | Z 2 CN 18-10-Az | SUS 304LN | X 2 CrNiN 1811 | 23 71 | |||||
| 305 | Z 8 CN 18-12 | SUS 305 | X 8 CrNi 1812 | 23 33 | 305S19 | X 8 CrNi 18 12 | X 8 CrNi 18-12 | |||
| Z 6 CNU 18-10 | SUS XM7 | X 6 CrNiCu 18 10 4 Kd | ||||||||
| 309 | X 15 CrNiS 20 12 | 1.4828 | Z 15 CN 24-13 | SUH 309 | X 16 CrNi 2314 | 309S24 | X 15 CrNi 23 13 | |||
| 309 S | SUS 309S | X 6 CrNi 2314 | X 6 CrNi 22 13 | |||||||
| 310 | X 12 CrNi 25 21 | 1.4845 | SUH 310 | X 22 CrNi 2520 | 310S24 | 20KH23N18 | ||||
| 310 S | X 12 CrNi 25 20 | 1.4842 | Z 12 CN 25-20 | SUS 310S | X 5 CrNi 2520 | 23 61 | X 6 CrNi 25 20 | 10KH23N18 | ||
| 314 | X 15 CrNiSi 25 20 | 1.4841 | Z 12 CNS 25-20 | X 16 CrNiSi 2520 | X 15 CrNiSi 25 20 | 20KH25N20S2 | ||||
| 316 | X 5 CrNiMo 17 12 2 | 1.4401 | Z 6 CND 17-11 | SUS 316 | X 5 CrNiMo 1712 | 23 47 | 316S31 | X 6 CrNiMo 17 12 2 | X 6 CrNiMo 17-12-03 | |
| 316 | X 5 CrNiMo 17 13 3 | 1.4436 | Z 6 CND 17-12 | SUS 316 | X 5 CrNiMo 1713 | 23 43 | 316S33 | X 6 CrNiMo 17 13 3 | X 6 CrNiMo 17-12-03 | |
| 316 F | X 12 CrNiMoS 18 11 | 1.4427 | ||||||||
| 316 N | SUS 316N | |||||||||
| 316 H | SUS F 316H | X 8 CrNiMo 1712 | X 5 CrNiMo 17-12 | |||||||
| 316 H | X 8 CrNiMo 1713 | X 6 CrNiMo 17-12-03 | ||||||||
| 316 L | X 2 CrNiMo 17 13 2 | 1.4404 | Z 2 CND 17-12 | SUS 316L | X 2 CrNiMo 1712 | 23 48 | 316S11 | X 3 CrNiMo 17 12 2 | X 2 CrNiMo 17-12-03 | 03KH17N14M2 |
| X 2 CrNiMoN 17 12 2 | 1.4406 | Z 2 CND 17-12-Az | SUS 316LN | X 2 CrNiMoN 1712 | ||||||
| 316 L | X 2 CrNiMo 18 14 3 | 1.4435 | Z 2 CND 17-13 | X 2 CrNiMo 1713 | 23 53 | 316S13 | X 3 CrNiMo 17 13 3 | X 2 CrNiMo 17-12-03 | 03KH16N15M3 | |
| X 2 CrNiMoN 17 13 3 | 1.4429 | Z 2 CND 17-13-Az | X 2 CrNiMoN 1713 | 23 75 | ||||||
| X 6 CrNiMoTi 17 12 2 | 1.4571 | Z6 CNDT 17-12 | X 6 CrNiMoTi 1712 | 23 50 | 320S31 | X 6 CrNiMoTi 17 12 2 | X 6 CrNiMoTi 17-12-03 | 08KH17N13M2T | ||
| 10KH17N13M2T | ||||||||||
| X 10 CrNiMoTi 18 12 | 1.4573 | X 6 CrNiMoTi 1713 | 320S33 | X 6 CrNiMoTI 17 13 3 | X 6 CrNiMoTi 17-12-03 | 08KH17N13M2T | ||||
| 10KH17N13M2T | ||||||||||
| X 6 CrNiMoNb 17 12 2 | 1.458 | Z 6 CNDNb 17-12 | X 6 CrNiMoNb 1712 | X 6 CrNiMoNb 17 12 2 | 08KH16N13M2B | |||||
| X 10 CrNiMoNb 18 12 | 1.4583 | X 6 CrNiMoNb 1713 | X 6 CrNiMoNb 17 13 3 | 09KH16N15M3B |
